Building a better world, one house at a time!
The Roof Team
Ed Chris Walter Theo James Jason
STEP 1
The first part of the roof construction consisted of the half trusses
being lifted onto the walls and placing them into sets of two to cover the entire house
Heading 3
DSCN9539
DSCN9661
DSCN9663
DSCN9539
1/15
STEP 2
Once the half trusses have been lifted onto the walls they
are placed into sets of two so that each pair could be joined to form a single truss and place at a distance of 760 mm
DSCN9136
DSCN9252
DSCN9652
DSCN9136
1/16
STEP 3
The trusses are kept apart at a distance of 760 mm with
the use of 38 x 50 battens
DSCN9377
DSCN9573
DSCN9339
DSCN9377
1/8
STEP 4
After the trusses had been placed at an equidistance of 760 mm, the roof is covered with a waterproof membrane to prevent leaks, after which the 38 x 50 battens are added to the top of the trusses at a distance of 350 mm apart.
DSCN0212
DSCN0194
Add a Title
Describe your image
DSCN0212
1/4
STEP 5
The interlocking cement tiles are placed onto the 38 x 50 battens and are attached to the battens with 60 mm galvanized roof screws.
DSCN9904
Theo 1
DSCN0214
DSCN9904
1/12
